Celto Acoustique CT15V 15″, 500W full range

Power Capacity (AES Standard)

500W RMS / 2000W Peak

Nominal impedance

8 Ohm

Frequency response (-6dB half space, no EQ)

50~22000Hz

Manufacturing Consistency tolerance

±1.5dB from 300 to 10000Hz

Average Sensitivity

98dB/W/m (wideband 200~16000Hz)

Maximum Calculated SPL @ 1m

126dB continuous / 133dB Peak

Nominal Directivity (-6dB)

80° x 50° above 1200Hz

Recommended low cut filter

50Hz 24dB/oct in full range mode,80-120Hz with subwoofer

Low Frequency driver

Custom made 15″ driver, Ferrite magnet, 3” in/out Voice coil

High Frequency driver

1” exit CELTO ACD40, 1.7” Voice coil, HSP Annular Ring Radiator

Crossover

Passive mode only 1800Hz, 12dB/oct on LF,18dB/oct on HF with T-Comp type II HF protection

Flying hardware

10 M8 points

Connectors

2x NEUTRIK SpeakON® NL4MP

Floor Monitor use

Yes, 2 symmetric angles

Pole mount

35mm top hat (0° and 10° angles)

Cabinet

CNC made with tongue and grove assembly,18mm birch plywood

Finish

Black Textured Waterborne Coating

Size (WxHxD)

445 x 710 x 414 mm

Weight

25kg net, 29kg gross
